Industrial M.2 PCIe Expansion Card

Cervoz_MEC-WIFI-2632B-30
Cervoz_MEC-WIFI-2632B-30

MEC-WIFI-2632B-30

Industrial M.2 PCIe Expansion Card

Features

  • Form factor: NGFF M.2 2230 type
  • IEEE 802.11a/b/g/n/ac draft 2.0 compatible WLAN
  • WLAN supports 2.4GHz and 5GHz channel
  • 2T2R MIMO technology for extended reception robustness and exceptional throughput
  • Bluetooth: BT 2.1/3.0/4.0/4.1/4.2/5.0
  • Max. PHY data rate: 866.7Mpbs using 80MHz bandwidth
  • I/O: WLAN: PCIe1.1. BT: USB 2.0
  • 2 x 50 Ohm RF connectors for 2.4G/5G diversity data transmission
  • RoHS compliant
MEC-WIFI-2632B-30 is a highly integrated single-chip that support 2-stream 802.11ac solutions with Multi-user MIMO (Multiple-Input , Multiple-Output) with Wireless LAN (WLAN) PCI Express network interface controller with integrated Bluetooth Smart Ready USB interface controller. It combines a WLAN MAC, a 2T2R capable WLAN baseband, and RF in s single chip.

MEC-WIFI-2632B-30 provides a complete solution for a high- performance integrated wireless and Bluetooth device.





Solution
WiFi
Form Factor
M.2 (A+E key) 2230
Interface
WLAN: PCIe 1.1 / Bluetooth: USB2.0
Frequency Range
802.11 a/b/g/n/ac + Bluetooth 5.0
Chipset
Realtek RTL8822CE
T/R
2T2R
Dimensions (WxL/ mm)
30.0 x 22.0
Operation Temp.
0 ~ 70°C
Driver Support
Windows 10, Linux, Android 6.0
Warranty
1 year
Model No. Description
MEC-WIFI-2632B-30 WLAN 802.11 a/b/g/n/ac, 2T2R+BT 5.0, NGFF Card M.2 Type 2230 A+E key


Date Document Type Capacity
2023.10.31 WiFi Solution_MEC-WIFI-2632B-30_Drvier_Linux 56.14 MB
2023.10.31 WiFi Solution_MEC-WIFI-2632B-30_Drvier_Windows 10 38.56 MB
2022.07.14 WiFi Solution_MEC-WIFI-2632B-30_Datasheet 0.54 MB
