MEC-DIS-M002
Industrial Mini PCIe Expansion Card
Features
- Single-Lane (x1) PCI-Express with throughput up to 2.5Gbps
- Fully compliant with PCI-Express Base Specification Rev. 1.1
- Support simultaneously dual display output
- Industry- Leading 2D acceleration graphic engine
- On board video memory with 16MB DDR SDRAM
- Support 1280 x 1024 @ 60Hz DVI /VGA resolution
MEC-DIS-M002 is a graphic card for embedded PC. The card follows the Mini PCI-e standard which is complaint with PCI Express x 1 classification and small form factor (30.00 x 50.95 mm). This board fits in any host computer that has Mini PCI-e card slots.
MEC-DIS-M002 supports simultaneous dual display outputs, which are VGA and DVI outputs. The 2D acceleration graphic engine and embedded DDR memory efficiently reduce CPU loading and produce outstanding graphics performance.
MEC-DIS-M002 is tested to be compatible with various Windows Operation Systems. The daughter board with bracket (1 DVI-I connector) and connection cable are included in the standard package.
MECFIX is the unique mounting mechanism designed specially for MEC daughterboard. The feature of the mounting unit allows the following mounting options:
1. Standard PCI/PCIe Bracket
2. Low Profile PCI/PCIe Bracket
3. Internal Mounting inside of PC system from any position and angle.
4. Customizing Front/Rear Plate of PC system according to dimension of MEC daughterboard.
Top Performance
MEC-DIS-M002 supports simultaneous dual display outputs, which are VGA and DVI outputs. The 2D acceleration graphic engine and embedded DDR memory efficiently reduce CPU loading and produce outstanding graphics performance.
High Usability
MEC-DIS-M002 is tested to be compatible with various Windows Operation Systems. The daughter board with bracket (1 DVI-I connector) and connection cable are included in the standard package.
MECFIX – Versatile Mounting
MECFIX is the unique mounting mechanism designed specially for MEC daughterboard. The feature of the mounting unit allows the following mounting options:
1. Standard PCI/PCIe Bracket
2. Low Profile PCI/PCIe Bracket
3. Internal Mounting inside of PC system from any position and angle.
4. Customizing Front/Rear Plate of PC system according to dimension of MEC daughterboard.
Solution
Display
Form Factor
Mini-PCIe
Interface
DVI x 1 (Support DVI, VGA)
PCI-Express Revision
PCI-Express Base Specification Rev 2.0
Electromechanical Revision
PCI-Express Mini Card Electromechanical Rev. 2.0
Dimensions (WxL/ mm)
30.00 x 50.95
Controllers
SiliconMotion SM750 with 16MB DDR SDRAM
Bus
Single-Lane (x1) PCI-Express with throughput up to 5.0/2.5Gbps
Performance
DVI Resolution: Up to 1280 x 1024, 60Hz, VGA Resolution : Up to 1280 x 1024, 60Hz
Power Consumption
740mA@3.3V
Operation Temp.
0 ~ 70°C
Storage Temp.
–40°C ~ 95°C
MECFIX
✓
Driver Support
Win 2003, Win XP, Win Vista, Win 7, Win 8
Warranty
3 years
| Model No. | Description |
|---|---|
| MEC-DIS-M002 | Mini PCI-e DVI/VGA output graphic board |
